Sacrifice
Sacrifice Forks Bionic Scs
The Bionic SCS forks are slick and slender, but incredibly strong with a 4-step telescoped shaft, giving strength in the areas that are needed most, and losing material where it isn’t.
They incorporate the unique nut trap design, that only Sacrifice product have which makes it simple to tighten the axle with just one tool
They also come with easy fit chrome plated, steel spacers, to ensure quick and precise assembly.
Spec:
Cold forged 6061-T6 AL
Shaft length (Above Crown Race): 150mm
Shaft Outer Diameter (with shim): 28.5mm (1 1/8”)
Fork Offset (Rake): 9mm
Max Wheel Size: 110mm
Weight: 279g (body Only)
Features:
4 Step telescopic shaft, built in M6 thread,
Integrated crown race, nut trap design for single tool assembly,
Integrated spacers, M8 high tensile axel, laser etched logo details
Spacers for running pegs.
They incorporate the unique nut trap design, that only Sacrifice product have which makes it simple to tighten the axle with just one tool
They also come with easy fit chrome plated, steel spacers, to ensure quick and precise assembly.
Spec:
Cold forged 6061-T6 AL
Shaft length (Above Crown Race): 150mm
Shaft Outer Diameter (with shim): 28.5mm (1 1/8”)
Fork Offset (Rake): 9mm
Max Wheel Size: 110mm
Weight: 279g (body Only)
Features:
4 Step telescopic shaft, built in M6 thread,
Integrated crown race, nut trap design for single tool assembly,
Integrated spacers, M8 high tensile axel, laser etched logo details
Spacers for running pegs.
